EYC Thermal Mass Flow Transmitter FTM94FTM95

Input type：Pt20 / Pt300(Air velocity), Pt1000(Temp.)

Measuring range：0 ... 120 Nm/s

Output signal：4 ... 20 mA / 0 ... 10 V / RS-485 / Impulse

Accuracy：±1.5%

Installation：Duct type / Remote type

IP rating：IP67

IP67 Rugged aluminum alloy case, fit in variety harsh environment

Easy to install, high accuracy, long-term stability

Switchable physical quantities : m/s, ft/s, Nm3 /h, Nm/s, L/min, m3 /min (Air velocity & volume)

LCD Display of air velocity and temperature

LCD Display of cumulative flow : m3 , L (Option)

Exhaust gas removal / Dust environment / Slightly corrosive environment / Burner feeder /

Biotechnology industry / Factory building air intake / Exhaust calculation
