EYC Thermal Mass Air Velocity and Air Volume Transmitter FTM06C-A

₱0.00

Brand: EYC

Model: FTM06C-A

Brand: EYC

Model: FTM06C-A

  • Output：4 ... 20 mA & RS-485 / 0 ... 10 V & RS-485 / RS-485 & Impulse (1 ... 500 Hz)

    Input：Pt20/Pt300 (Air velocity) / Pt1000 (Temp.)

    Measuring range：0 ... 5 m/s ~ 0 ... 60 m/s

    Accuracy：±1.5% (Option±1%)

    IP rating：IP65

  • Thermal mass flow, quickly response, good sensitivity

    Turndown ratio 500：1, high precision & accurate sensing at lowest flow rate for metering applications

    Display Instantaneous flow, the cumulative flow can be displayed in the software

    Output：Analog / RS-485

    Use measured with square pipe or 2" pipe above

    IP rating：IP65

    Stainless steel casing, suitable for various severe environments, such as slightly corrosive air

  • Compressed air monitoring / Exhaust gas emission flow monitoring / Special gas process / Semiconductor / electronics factory / Industrial process air velocity and air volume measurement
