Sensor Type：Thermal mass flow sensor
Air Velocity Measuring Range：0.15 ... 90 m/s
Air Velocity min. Measuring Range：0.15 m/s
Temp. Sensor / Measuring Range：Pt1000, 0 ... 80°C
Accuracy(+25°C)：Air velocity：±1.5%F.S.
Output：0 ... 20 mA / 4 ... 20 mA / 0 ... 1 V / 0 ... 5 V / 0 ... 10 V
Display：Optional
-
IP rating：IP67, rugged aluminum case, fit in variety harsh environment
Capable of temperature compensation
Linear calibration air velocity by computer, analog output or RS-485(Optional)
High-speed, high-accuracy measurement, quickly respond
Thermal mass flow sensor
LCD, display air velocity and temperature
Switch multifunction physical quantities：[m/s]、[ft/s]、[km/h]、[mph]、[kont]
DIP SWITCH and RS-485 function
Follow customer needs to plan measuring range, analog output, stations, and zero-point OFF SET or RS-485 adjustment zero-point OFF SET
Free programmable software : Data logger / Maximum record 65535 data / Charts
-
Monitor air velocity in supplying gas consumption dry process in industry process / Compressed air consumption measurement / Building / Factory / Clean room / Hospitals / Semiconductor / Electronics / Paper / Printing / Textiles / Steel and iron Industry / Food / Chemical / Pharmaceutical / Biotechnology industry
