Sensor type : Thermal mass flow sensor
Air velocity measuring range : 2 m/s ; 10 m/s；20 m/s；40 m/s
Air velocity min. measuring range : 0.2 m/s
Accuracy( +25°C ) : Air velocity : ± 2 % F.S.
Output : 4 ... 20 mA / DC 0 ... 10 V
Display：Optional
-
Linear adjustment function
Switch for physical quantity：[m/s]、[ft/s]、[km/h]、[mph]、[knot]
Option RS-485 Communication Interface, Modbus RTU protocol
Configuration measuring range, analog output, station number by dip switch & RS-485
Off SET function by bottom or RS-485
Programmable softeware ： DATA LOGGER, record, and chart analysis
-
Monitor gas and flow for industrial process / HVAC / Building / Factory / Clean room / Hospital / Semiconductor / Electronics / Paper / Environment / Food / Pharmaceutical / Biotechnology industry
