EYC Air Velocity Transmitter FTS34FTS35

Sensor type : Thermal mass flow sensor

Air velocity measuring range : 2 m/s ; 10 m/s；20 m/s；40 m/s

Air velocity min. measuring range : 0.2 m/s

Accuracy( +25°C ) : Air velocity : ± 2 % F.S.

Output : 4 ... 20 mA / DC 0 ... 10 V

Display：Optional

Linear adjustment function

Switch for physical quantity：[m/s]、[ft/s]、[km/h]、[mph]、[knot]

Option RS-485 Communication Interface, Modbus RTU protocol

Configuration measuring range, analog output, station number by dip switch & RS-485

Off SET function by bottom or RS-485

Programmable softeware ： DATA LOGGER, record, and chart analysis

Monitor gas and flow for industrial process / HVAC / Building / Factory / Clean room / Hospital / Semiconductor / Electronics / Paper / Environment / Food / Pharmaceutical / Biotechnology industry
